Wireless HDMI Extender Only – Up To 30M ( 4K@30Hz )
Color: Black
Overview:
- Support up to 4 Transmitter to 1 Receiver
- Compatible with HDMI1.4 standard, resolution is 3840 X 2160@30Hz
- Support HDCP1.4 standard-high bandwidth digital content protection technology
- Supports wireless with a maximum transmission distance of 30m
- Support HDMI total bandwidth 10.2Gbps
- Plug and play
Specification:
| HDMI 1.4 , HDCP 1.4 | Standards |
TX: HDMI-A RX: Mini HDMI | Interface Type |
| 340MHz , digital | Pixel Bandwidth |
HDMI total bandwidth 10.2Gbps | Interface Bandwidth |
| Max: 3840 X 2160@30Hz | Resolution |
| Up to 4 TX to 1 RX | TX to RX Ratio |
| 100Ω | Impedance |
| ≤30M | Transmission Distance |
| DC 5V | Power Supply |
| MAX 3.5W | Power dissipation |
| Operating：-5℃ ~ +70℃ | Temperature |
| Operating：5% ~ 90% | Humidity |
TX: 62*24*11 mm RX: 65*40*18.2 mm | Dimension |
Package includes:
- Transmitter (Only)
- Mini HDMI to HDMI-A
- 2x USB type A to C Cable
- User manual
